Features
Easy Calibration
Quick calibration
after installation
Multiple Work Modes
Straight Lines/Curves
/Automatic U-turn
High Accuracy
After creating a project,
upload the icon
Intuitive Software
2D/ 3D Software,
easy to learn and use
Main Components
➤ GPS L1/L2/L5, GLONASS L1/L2, BDS B1/B2/B3, Galileo E1/E5a/E5b, SBAS and L-Band
➤ Low noise amplifier and high gain
➤ Millimeter level phase center error
➤ Outstanding stability and repeatability
➤ >100Hz data processing speed
➤ 3-Axis Gyroscope, nimble and accurate reaction
➤ Fast and convenient installation
➤ Android OS, Support BT, WIFI, Dual-SIM 4G
➤ 10.1 inch screen, 1280 * 720 Resolution
➤ K8 Series GNSS modules inside, high accuracy positioning
➤ Aluminum-magnesium alloy, Rugged design, IP66
➤ Intuitive Software with abundant functions
➤ Low noise, low heat
➤ High Torque, high accuracy
➤ Mountable for most brands of tractors
All Farming Procedures
Ridging
Seeding
Spraying
Harvesting
Product Video
Specifications
Positioning Accuracy
| Real time kinematics (RTK) | 8mm+1ppm (Horizontal)
15mm+1ppm (Vertical) |
| Velocity accuracy | <0.02 m/s |
| Initialization Time | <10 s |
| Initialization reliability | 99.9% |
Performance
| Pass to pass accuracy | ±2.5cm |
| Work speed | 0.1~20km/h |
| Work scene | Low / High speed
Straight / Curve Automatic U-turn |
Physical
| Operating Temperature | -30°C~+70°C |
| Storage Temperature | -40°C~+85°C |
Electric Streering Wheel
| Power input | 12V~24V |
| Torque | 6.2 N·m |
| Wheel diameter | 171 mm |
| Motor height | 94.3 mm |
GNSS Tablet
| Size | 10.1” |
| Resolution Rate | 1280*720 |
| Memory | 2GB RAM (4GB is optional)
16G ROM (64GB is optional) |
| Operating System | Android 7.1 |
| Waterproof and dustproof | IP66 |
Signal Tracking
| GPS | L1C/A,L2C,L2P |
| BDS | B1l,B3l |
| BDS Global | B1C,B2b |
| GLONASS | G1,G2 |
| Galileo | E1,E5b |
| QZSS | L1,L2 |
Communication and Data
| Wifi/Bluetooth | Yes |
| Type C port | 1 |
| USB port | 3 |
| TF card slot | 1 |
| Dual-SIM card slot | 1 |
| GNSS Antenna port | 2 |
| UHF Antenna port | 1 |
| 4G antenna port | 1 |
| Lemo port | 3 (including RS232/RJ45 PPS/EVENT/CAN/USB) |
Documents
SinoGNSS AG502 Autosteer Syste Release Date: 2023.12.21 Version: 1.0
